Conservatories by Protech Direct

More Videos From Protech Direct

Victorian Conservatory Features

All conservatories incorporate two opening vents as standard
25° pitched roof
Finial and ridge cresting
Opal polycarbonate roofing
FREE upgrade to french doors
Toughened safety glass to BS6206A
Squareline gutter profile 24mm sealed double glazed units to BS5713
Five point locking system to doors Dwarf wall or full height models available
Free Upgrade from C Rated to A Rated Glass - Click Here for more details
Internally Glazed
Available in White, Woodgrain, Woodgrain and White and Light Oak
All profiles have been tested to British Standards (BS7143)
Door handles are available in white as standard (Gold and Chrome available at extra cost)
28mm sealed unit reduces noise and provides additional thermal insulation
The glazed units are fixed with internal beads for enhanced security
The patio system is availble with high security hardware
For smoother opening, Woolpile Weathershields are fitted
Anti-theft blocks Stainless steel track, stainless steel rollers

Edwardian Conservatory Features

All conservatories incorporate two opening vents as standard
25° pitched roof
Finial and ridge cresting
Opal polycarbonate roofing
FREE upgrade to french doors
Toughened safety glass to BS6206A
Squareline gutter profile
24mm sealed double glazed units to BS5713
Five point locking system to doors
Dwarf wall or full height models available

Lean-to Conservatory Features

All conservatories incorporate two opening vents as standard
2.5° pitched roof
Opal polycarbonate roofing
FREE upgrade to french doors on models 3L4 and 3L5 only, 3L3 only has a single door, and so cannot be upgraded
Toughened safety glass to BS6206A
Squareline gutter profile
24mm sealed double glazed units to BS5713
Five point locking system to doors
Dwarf wall or full height models available

Included in Easyframe conservatories kits:-

All parts clearly labeled for easy identification
Packed against damage during delivery
Full parts list for identification
Guide to building your base and dwarf wall
Comprehensive installation manual
Telephone support during installation (office hours only). In the event of a problem that cannot be
resolved via the telephone and digital images or sketches, a trained engineer will visit the site. If there is a product fault it will be rectified by Easyframe Conservatories. If it is an installation fault there will be a site visit charge of £95.00 plus vat = £111.62, this service is only available UK mainland
Receipt and invoice sent within 5 days of order
Floor plans and manual posted within 7 days or available online
For your convenience we deliver the conservatory kit complete in one visit to site
All conservatories photographed prior to dispatch from the warehouse
Free delivery to UK mainland. For delivery to Northern Ireland and Southern Ireland please add £440. For off shore British Isles and othere countries please enquire. Conservatories have been shipped to and are in service in Japan, Germany, Portugal, USA, Falkland Islands, Isle of White and Outer Hebrides.
Reliable drivers and efficient transport system
Europes largest conservatory manufacturer
Manufacturers no quibble 10 year warranty
Unique construction method means two people could build the conservatory in a day
life expectency of at least 25 years
In the events of damaged caused during or after installation a comprehensive spare parts service is offered, parts can be dispatched within 24 hours subject to credit card payment
The whole conservatory designed, manufactured and British Standard tested by one company. For example wind and snow loadings apply to the whole conservatory and not just the roof as is the case in other conservatories. This is not a roof by one company with frames and doors by another. These conservatories are specifically designed for do it yourself installation
General conservatory specification
Fully weather proofed
Engineered to cope with all the extremes of weather that northern europe can throw at it
Wind and snow loadings calculated for strength and stability
Fully draught proofed
Fully water proofed
100% virgin pvcu profile manufactured in the UK
Reinforced with aluminium
External brickwork sizes given online

Conservatory roof specification

Aluminium roof bars for strength and stability
Clad with high grade 100% virgin pvcu inside and out for thermal insulation and low maintenance
Low sight line gaskets
All parts are pre drilled and cut to size for ease of installation
Ridge crest and decorative finial included (Edwardian and Victorian conservatories only)
22.5 degree pitch on E1-3 and V1-3models, 25 degree pitch on other victorian and edwardian modelsaids in "self cleaning" the roof
4 degree on 3L3 - 3L5 models 2.5 degree low pitch on the other lean to conservatories ideal for bungalows,2303mm (7foot 7") ridge height
All necessay bolts, screws and fixings

Multiwall Polycarbonate specification

25mm multiwall opal polycarbonate on all conservatories giving a U value of 1.3m2 and a weight of 3.8kg/m2
High insulation values, high impact resistance
Self extinguishing, flammability to BS476/7 Class 1
Considerabley reduces glare and heat build up but offering good light transmission
200 times stronger than glass of the same thickness
Anti-condensation coating
Fully UV stabalised
Will not yellow, degrade or crack
Cut to size and shape to save you time during installation on site
Blown, micropourous taped in order to stop dust, spours, spiders and mould from entering the cavities and allowing the sheets to breathe
Aluminium u capping to protect the exposed edges of the polycarbonate sheets
High grade 100% virgin pvcu square line guttering,brackets, down pipes and connectors included

Double Glazing Specification

Hermetically sealed insulating glass units as standard on all models
2x4mm toughened safety glass with a 16mm cavity - 24mm overall
Toughened safety glass to BS 6206 class A and clearly marked on all glass panels
Insulating glass units comply to BS 5713 U value of 2.65w/m2 ensuring a high insulation value

Glazing method specification

Fully drained and ventilated glazing system throughout
All insulating glass units held in place with hi-adhesive security glazing tape to BS
Impossible to de-glaze from outide
Glazing bead locked into outer frames for additional security and peace of mind
Attractive sculptured scotia glazing bead to windows and doors
Factory glazed as standard, no need to remove glass for erecting the conservatory further reducing time on site
Low sight line gasket throughout

French door specification

French doors as standard on all models
(single door on LT1 -and- LT4 lean to conservatory only)
All welded construction to doors and outer frame
Fully reinforced for additional security and stability
Both doors open out to leave as much usable space in your conservatory as possible
Restrictors available at £15.00 per door

Doors can be positioned as follows;
Edwardian conservatories -
...anywhere within the conservatory but not directly onto a corner
Victorian conservatories -
...anywhere to suit you're requirements.
Lean to -
...anywhere within the conservatory but not directly onto a corner

If positioning the french doors directly against your house wall you need a wall mullion kit at an additional cost of £38.00, this applies only to dwarf wall models

5 point multi-locking system approved by the Association Of British Insurers
Full length strike plate to slave door
Finger bolts to slave door
Locks pre-fitted in the factory
Handles easily fitted on site
Fully adjustable flag hinges
Full weather, water and draught proof dual seal gaskets to both doors and outer frames
White low maintenace hardware

Windows/side wall frame specification

All welded construction on windows and top light openers
Multi chamber 100% virgin pvcu extruded in the UK
Reinforced with aluminium for strength
Aluminium exterior cills for strength
Aluminium corner posts for strength
Aluminium ring beam (joins roof to frames) for strength and stability
Top opening casement windows specification
Two opening top lights as standard
More available @ £150.00 per pair
Espagnolette multi point locking with locking handles and push to release feature
Lockable night vent facility on all opening windows for trickle ventilation
Full weather, water and draught proof dual seal gaskets to sashes and outer frames
Adjustable stainless steel casement stays
White low maintenace hardware

Maintenance and periodic cleaning

All components are designed for long life and trouble free performance with minimal maintenance. We recommend that all pvcu, polycarbonate and aluminium parts are cleaned with hot soapy water only.
The surface of all toughened safety glass is much softer than float (ordinary window) glass and care should be taken NOT to scrape the surface when removing labels or cleaning. This information MUST be passed on to the installer.
During manufacturing, pvcu extrusions and polycarbonate roofing have protective tapes and films applied. These MUST be removed immediately after installation and not left for extended periods in the sun during storage. Failure to remove these tapes will cause damage to your conservatory.
All locks and moving parts should be cleaned and lubricated with a light oil periodically. Guttering should be cleaned and leaves/debris removed on a regular basis. Your installation manual and parts list should be keep for future reference.
In the event of damage to your conservatory, you will need the part numbers in order to obtain replacement parts. Spare parts will be available for at least ten years under the Easyframe customer care policy.
